Read this article to know the difference between solidworks and Autocad.
Here are the commonly asked solidworks interview questions and answers:
What is Solid works and its applications ?
Create two revolved bosses to round out the louver. Add a fillet around the bottom edge of the louver. Use an extruded cut to remove the base so that only the louver remains. Use the Forming Tool tool to convert the louver into a forming tool. Today, we are going to show you the simple steps you can take to easily create a sphere in Solidworks. Creating a Sphere in Solidworks Let’s take a close look at these three simple commands and see how they can help us on the quest of creating our sphere in Solidworks.
Hi guys, I need to get a fat pattern out of a cone with knuckle attached, please refer to the model. When I flat the sheet metal, I have got 364.61mm for chord cutout and 14.43° for chord radius insdead of correct ones 311mm and 12.3° calculated by 'plate n sheet'. So let’s see what this information would look like in SOLIDWORKS. As you can see there are some parametric solids and some cross-sections which are all in their relative location to each entity. From here, we need to use our simple modeling tools such as: extrudes, revolves, lofts, etc. To create a revolve feature, use the following guidelines: The sketch for a solid revolved feature can contain multiple intersecting profiles. With the Selected Contours pointer (available when you click Selected Contours in the PropertyManager), you can select one or more intersecting or non-intersecting sketches to create the revolve.
Solidworks is a computer aided design tool used for the design, manufacturing and simulation of mechanical products. This tool can be used in the complete product development cycle. Here are the applications of solidworks:
- Concept design
- Detailed Part and Assembly Design
- Structural and thermal analysis
- Motion studies
- Tolerance Analysis
- Engineering Drawings
- Manufacturing
- Inspection e.t.c.
What are templates in solid works?
Solidworks Templates store a set of rules or default settings in various solidworks modules.
What are configurations in solidworks?
Solidwork Configurations allow users to create multiple variations of a part and assemblies within one document. They provide a convenient way to develop and manage families of cad models with different dimensions, components, or other parameters.
For example a family of screws or nuts can be defined by configurations in solidworks.
How to create a new template in solid works ?
Here are the steps to create a new template in solidworks:
Step-1: Open the required SW module such as part, drawing or assembly.
Step-2: Modify required setting in solid works.
Step-3:
What are the applications of convert entities ?
Convert entities are used in solid works to draw sketches with reference to any feature of a part.
Step-1:
What is the use of relations in solid works?
Relations are used in solidworks sketch modules to define design intent. When we define a sketch, soliidworks automatically add relations. These relations can be edited manually as well.
Examples of Solidworks Sketch Relations include:
- Coincident, Midpoint, Merge and Pierce.
- Horizontal, Perpendicular Vertical and symmetric.
- Equal, Equal Slot.
- Co-linear, Parallel.
- Co-Radial, Concentric, Tangent and equal curvature.
- On edge, on plane, etc
What are equations in solid works?
Equations are used in solid works assembly and part modules to define the relationship in between two dimensions. Solidwork Equations use global variables and mathematical functions.
How to constraint Spline in solid works?
Following methods are used to constrain a spline in solidworks:
- Tangent/vertical/horizontal relations to spline direction.
- Dimensions on spline control.
- Constrain the position of spline points.
What are the types of pattern in solid works?
Here are the different types of patterns used in solidworks:
- Linear Pattern
- Circular pattern
- Curve driven pattern
- Sketch driven pattern
- Table driven pattern
- Fill pattern
- Variable pattern
How to insert a reference plane?
Step-1: Go to insert and select reference geometry.
Step-2: Select Add Plane.
Step-3: Select reference for plane.
Why shell feature is used in solidworks?
Shell is used to make uniform or variable thickness of a solid body.
How to insert a reference image in Solid Works?
Step-1: Open Sketch Module
Step-2: Go to Tools, Sketch Tools and then Sketch picture
Step-3: Browse the picture
Step-4: Open picture
How to insert a dwg file in SolidWorks?
What is the application of draft feature?
Draft feature is used to provide an angle to a wall from a parting plane. Draft angle is generally used to facilitate easy removal of injection molded parts from injection tool.
What is Hole wizard and how is it used in solidworks?
Hole wizard is a tool inside solidworks that allows to quickly create standard & customized holes within a part or assembly without using multiple features.
What are different types of pattern in solid works assembly?
- Linear component pattern
- Circular component pattern
- Pattern driven component pattern
- Sketch driven component pattern
- Curve driven component pattern
- Chain component pattern
- Mirror
What is the application of interference detection in solid works?
It is used to verify interference between two or more components in a solidworks assembly.
Step-1:
What is the application of clearance verification in solidworks?
Clearance Verification is used to verify the designed clearance in between two or more parts in a solidworks assembly.
Step-1: Go to Evaluate
Step-2: Select components to be excluded from study
Step-3: Define minimum acceptable clearance.
Step-4: Select the Calculate
How to calculate part / assembly weight in solid works?
Step-1: Ensure material or density of each part is defined.
Step-2: Click Evaluate
Step-3: Check Mass Properties.
How to determine center of mass of a part/assembly in solid works?
In part/assembly: Go to Insert -> Reference Geometry -> Center of Mass
In drawing View: Go to Insert -> Model Items -> in model Item property manager under reference geometry click center of mass.
How to convert a solid part into sheet metal in solid works?
Step-1: Go to sheet Metal Module.
Step-2: Click to Convert to sheet metal
Step-3: Select Fixed face (surface from where all bends will be defined)
Step-4: Specify sheet metal parameters such thickness, internal bend radius and k factor.
Step-5: Select bending edges
Step-6: Select rip edges (SW automatically selects rip edges)
Step-7: Select corner type and corner gaps
Step-8: click ok
How to modify k-factor, bend allowance or sheet thickness values in solid works?
Step 1: Go to feature manager
Step 2: Right click on sheet-metal
Step 3: Select edit feature
Step 4: Modify sheet metal parameters
What are the commonly used features in solid works surfacing?
- Extrude
- Revolve
- Sweep
- Loft
- Boundary Surface
- Offset
- Fill Surface
- Extend
- Trim
- Untrim
- Knit
How to make multi-body part in solid works?
To make any part multi-body part merge option need to be merged.
How to engrave a text in a solid works part?
Step-1: Go to Sketch
Step-2: Add the Text
Step-3: Extrude Cut or Extrude Base the text according to requirement.
What is the application of Circuit Works in Solidworks?
Circuit Works is used to create 3D models of PCB data. It converts PCB data into solid works cad format.
What are exploded views in solid works?
Exploded views are used to spread out components in an assembly.
Step-1 : Go to insert and select the exploded view or go to configuration manager and right click the configuration.
Step-2 : Select New exploded view
Step-3 : Select the part to be exploded and define orientation and distance.
Step-4 : Select apply and done.
What is the difference between suppress and the hide features in solidworks?
Suppressed part in solidworks is like a deleted part in an assembly while the hide is like a removed view of part in assembly.
What is a suppress tool in solidworks?
Suppressed part in solidworks is like a deleted part in an assembly that is easy to undo. When a part is suppressed all dependencies from that part is also suppressed (features, references, mass, BOM)
What are external references in solid works?
External reference is used in solidworks assembly to make one part with reference to another in an assembly.
How to copy complete assembly along with drawings, reference parts and aesthetic attributes?
Pack & Go feature is used to copy complete assembly with all associated parts, drawings and attributes.
Step-1 :
What are different mates used in solid works?
- Standard mates: coincident, parallel, perpendicular, tangent concentric, angle, distance
- Advanced mates : Profile center, symmetry, width, path mate, linear/linear coupler
- Mechanical Mates: Cam, slot, hinge, gear, rack pinion, screw, universal joint
How to make an assembly configuration in solidworks?
Step-1 : Go to configuration Manager
Step-2 : Right click part/assembly name
Step-3 : Click add configuration
Step-4 : Enter configuration name and description
Step-5 : Press ok
What are design tables in Solid works?
The Design Table is used in an assembly to control the configuration with the modification in excel sheet.
How to generate BOM in solid works?
Step-1: Go to insert
Step-2 : Select Table
Convert Models To Sheet Metal Solidworks
Step-3 : Click Bill of Material
Solidworks Sheet Metal Tutorial
What is speed pack in solid works assembly?
Speed Pack is used to create a simplified configuration of an assembly without losing references. While working with large and complex assemblies. Speed-Pack configuration can significantly improve performance.
